ATLAS COPCO Drilling Rigs - Land Rigs

Detailed Description

Land Rigs - 2003 Ingersoll-Rand RD20-III
Range III Derrick
120,000 Lbs. Pullback Capacity
Cummins QSK19 755 HP Engine (installed new 600 hours ago)
No In / Out Box Direct Drive
Two Motor 8,000 Lb.-Ft. Torque Spur Gear Powerhead (completely rebuilt 1,500 hours ago)
Seven Rod Carousel for 4-1/2" O.D. X 30' Drill Pipe
Ingersoll-Rand HR2.5 1250 cfm / 350 psi Air Compressor (currently removed from drill)
Four Hydraulic Outriggers Plus Two Manual Screw Jacks on Table
Sixty (60) gallon injection lubricator
CAT 35 GPM Water Injection Pump
225 Gallon Fuel Tank
Tattle Tale Indicator.
Torque Limit Control
Storage Box Under Cooler
Spindle Sub – 4 ½” x 2 7/8 IF
    Foremost Shock Sub
Mounted on a Crane Carrier Corp. 8X4 Four Axle Carrier P/B CAT C13 Engine
